| Performance Parameter | Unit | Value |
| Max. torque | kN.m | 250 |
| Max. drilling diameter | mm | 2000 |
| Max. drilling depth | m | 31.2 |
| Working speed | rpm | 6~26 |
| Max. cylinder pressure | kN | 220 |
| Max. hoist capacity | kN | 220 |
| Main winch pull force | kN | 230 |
| Main winch speed | m/min | 80 |
| Auxiliary winch pull force | kN | 110 |
| Auxiliary winch speed | m/min | 75 |
| Max. cylinder stroke | mm | 2000 |
| Mast side raking | ° | ±5 |
| Mast raking forward | ° | 5 |
| System pressure | mpa | 35 |
| Pilot pressure | mpa | 3.9 |
| Max. walking speed | km/h | 1.5 |
| Max. pull force | kN | 510 |
| Operating height | mm | 10915 |
| Operating width | mm | 4300 |
| Transport height | mm | 3395 |
| Transport width | mm | 3000 |
| Transport length | mm | 10645 |
| Total weight | t | 69 |
| Engine type | QSL9 | |
| Engine form | Water cooled, six cylinder line, turbocharged | |
| Cylinder number*cylinder diameter*stroke | mm | 6×114×145 |
| Displacement | L | 8.9 |
| Rated power | kw/rpm | 232/1900 |
| Max. torque | N.m/rpm | 1424/1500 |
| Emission standard | EUⅢ |
| Model | Interlocking | |
| Outer diameter | φ650 | |
| Layers*Length of each section | 8×5.3 | |
| Max.depth | 31.2 |
| Track width | mm | 3000~4500 |
| Width of track plate | mm | 800 |
 |
 |
 |
 |
