| Performance Parameter | Unit | Value |
| Max. torque | kN.m | 220 |
| Max. drilling diameter | mm | 1800/2000 |
| Max. drilling depth | m | 64/51 |
| Working speed | rpm | 6~28 |
| Max. cylinder pressure | kN | 210 |
| Max. hoist capacity | kN | 220 |
| Main winch pull force | kN | 230 |
| Main winch speed | m/min | 60 |
| Auxiliary winch pull force | kN | 90 |
| Auxiliary winch speed | m/min | 60 |
| Max. cylinder stroke | mm | 5000 |
| Mast side raking | ° | ±5 |
| Mast raking forward | ° | 5 |
| System pressure | mpa | 35 |
| Pilot pressure | mpa | 4 |
| Max. walking speed | km/h | 2.2 |
| Max. pull force | kN | 430 |
| Operating height | mm | 21082 |
| Operating width | mm | 4300 |
| Transport height | mm | 3360 |
| Transport width | mm | 3000 |
| Transport length | mm | 15300 |
| Total weight | t | 66 |
| Engine type | CAT-7.1 | ||
| Engine form | Water-cooled, 6 cylinder line, turbocharged | ||
| Air intake form | Turbocharged inter-cooled | ||
| Cylinder number*cylinder diameter*stroke | mm | 6×112×140 | |
| Displacement | L | 7.2 | |
| Rated power | kw/rpm | 195/2000 | |
| Max. torque | N.m/rpm | ||
| Emission standard | EUⅢ | ||
| Model | Friction | Interlocking | |
| Outer diameter | φ440 | φ440 | |
| Layers*Length of each section | 5×14 | 4×14 | |
| Max.depth | 64 | 51 | |
| Chassis type | CAT330 | ||
| Track width | mm | 3000~4300 | |
| Width of track plate | mm | 800 | |
| Tail radius of rotation | mm | 3780 | |
 |
 |
 |
 |
 |
 |
